AMD Zynq Ultrascale+ - ONDA Plus SOM

PREVIEW

Processor AMD Zynq® UltraScale+™ MPSoC

In the new era of Internet Of Things, customers are requiring to add connectivity and new functionalities on their products. Customers are also keen to product longevity and hardware/software maintenance. For these reasons DAVE Embedded Systems has designed a new solution based on AMD Zynq® UltraScale+™ MPSoC devices EG family usefukl for any harsh environment including the defense and space market.

Dual- and quad-core application processor equipped devices deliver maximum scalability, and are capable of offloading critical applications, such as graphics and video pipelining, to dedicated processing blocks, along with a full complement of integrated peripherals and connectivity cores suitable for next-generation systems. For the most compute intensive processing tasks, integrated programmable logic offers up to 100X performance improvement over processor-based implementations. With this design, DAVE Embedded Systems provides its customers with a platform that benefits of the latest AMD technology together with the compatibility with the existing SoM product line. Business continuity and product maintenance are the key words around this product including high reliability options like conformal coating, sealing and lead process manufacturing for avionic and defense applications.

Main Features

Up to 4 ARM® Cortex™- A53 Processor
Two ARM Cortex™- R5 Real-time Processors
ARM Mali™- 400 Graphic Processing Unit
Platform Management Unit for Power and Safety Management
Config and Security Unit
Programmable Logic with High Speed Transceivers
DDR4 memory on board up to 64bits bandwidth
Designed for industrial environment
No restrictions for SOC: all SOC features available including the high speed SERDES
CG/EG support from ZU9 and ZU15 families
Suitable for Defense grade manufacturing with led finishing, conformal coating and sealing

Datasheet

Technical Information

CPU	AMD Zynq™ UltraScale+™ MPSoC EG Device with: Quad-core Arm Cortex-A53 MPCore™ up to 1.5 GHz Dual-core Arm Cortex-R5F MPCore up to 600 MHz Supported XCZU9EG and XCUZU15EG
Supervisor	On-board power supply supervision
Memory	SDRAM: Up to 8GB LPDDR4 NOR: Bootable QSPI NOR 8, 16 MB eMMC: up to 128GB pSLC
Interfaces	2xUSB 3.0 2xPCIe Gen2 LAN: Ethernet 10/100/1000 Mbps 3x Additional RGMII interface UART: up to 2x UART ports USB: up to 2x 2.0 OTG port CAN: up to 2x CAN Debug: JTAG IEEE 1149.1 Test Access Port CoreSight™ and Program Trace Macrocell (PTM) Other: 2 x SD/SDIO 2.0/MMC 3.31 up to 2 x I²C channels up to 2 x SPI channels up to 328 GPIOs available
FPGA	Logic Cells: 600K to 747K LUTs: 17K to 53K Flip Flops: 35K to 100K Total RAM: 40.9Mb to 69Mb DSP Slices: 2520 to 3528 24x 16.3Gb/s tranceivers
Mechanical	Connectors: 3 x 320 pin 0.63mm pitch Size: 84mm x 56mm Temperature range: Commercial (0°C / +70°C) temperature range Industrial (-40°C / +85°C) temperature range Defense grade (-40°C / +125°C) temperature range
Power Supply	Input: 3.3V, on-board voltage regulation
Software	Bootloader: U-Boot Multitasking: Linux 3.x.x
